技术参数
| 旋直径mm | 螺距mm |
转速r/min/
输送量m3/h
|
转速r/min/
输送量m3/h
|
转速r/min/
输送量m3/h
|
转速r/min/输送量m3/h |
| 100 | 100 | 140/2.2 | 112/1.7 | 90/1.4 | 71/1.1 |
| 160 | 160 | 112/8 | 90/7 | 71/6 | 50/4 |
| 200 | 200 | 100/14 | 80/12 | 63/10 | 50/7 |
| 250 | 250 | 90/24 | 71/20 | 56/16 | 45/13 |
| 315 | 315 | 80/34 | 63/26 | 50/21 | 40/16 |
| 400 | 355 | 71/64 | 56/52 | 45/41 | 36/34 |
| 510 | 400 | 63/100 | 50/80 | 45/64 | 32/52 |
| 630 | 450 | 50/145 | 40/116 | 32/94 | 25/80 |
| 800 | 500 | 40/208 | 32/94 | 25/130 | 20/110 |
| 1000 | 560 | 32/300 | 25/230 | 20/180 | 16/150 |
| 1250 | 630 | 20/388 | 20/320 | 16/260 | 13/200 |
